EX-6100PoE is a Gigabit Ethernet switch in metal housing with PoE function for up to 4 end devices such as IP phones, IP cameras, WLAN access points, etc. It supports 10/100/1000 Base-T Ethernet standard and is fully compliant with IEEE 802.3af/at POE standards. The EX-6100PoE operates as Power Source Equipment (PSE) = 34.20 W for the Powered Device (PD) = 25.50 W. The required power is supplied via the +48 - 57 V terminal block. The EX-6100PoE provides the user with greater installation flexibility by eliminating the need for the terminal device to be located in close proximity to a power outlet. It can also be used in the extended temperature range of -40C° to +85C°. 5x 10/100/1000Mbps Ethernet RJ45 ports Power up to 4 PoE-capable remote network devices, transfers data and power on one single cable Fully IEEE 802.3af/at compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W Maximum Power Delivered (PD): Type 1: 12.95W / Type 2: 25.50W Supports a extended temperature range from -40°C up to +85°C Supports Jumbo Frames up to 9K Bytes Auto-MDI/MDIX eliminates the need for crossover cables Plug and play, no configuration and installation required Terminal block for DC input 48V to 57VDC ED status indicator of PoE power supply for each port Small, rugged metal housing for critical applications Wall or DIN-Rail mounting Packaging contents:EX-6100PoE, DIN-Rail Kit, Manual

The EX-6200-T is a compact industrial 5-port Ethernet unmanaged switch in a metal housing. It can be used in an extended temperature range from -40C° to +75C° and offers increased operational reliability thanks to the redundant power supply of 2x 12 V - 48 VDC via a terminal block. 5-Port 10/100Tx Fast Ethernet Supports the extended temperature range from -40°C to +75°C Auto-MDI-MDIX, does not require a “crossover cable” Plug and play, no configuration and installation required Terminal block for redundant DC input, 2x 12 V to 48 VDC Robust Metal Case, IP30 Incl. DIN-Rail Kit and Metal Plate for wall mounting Packaging contents:EX-6200-T, RJ45 Protection caps, Wall Mounting Brackets, DIN-Rail Kit, Manual

The EX-6220 is an ultra-compact industrial 5-port Gigabit Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block. 5-port 10/100/1000Tx Gigabit Ethernet Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Terminal block for redundant DC input, 2x 12V to 48VDC Robust, ultra-compact metal housing, IP30 DIN-Rail Kit and metal plate for wall mounting Operating temperature range from -10°C to +65°C Packaging contents:EX-6220, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The EX-6221 is an industrial 5-port Gigabit Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block. 5-port 10/100/1000Tx Gigabit Ethernet Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Terminal block for redundant DC input, 2x 12V to 48VDC Built-in relay output warning for power failure Robust metal housing, IP30 DIN-Rail Kit and metal plate for wall mounting Operating temperature range from -10°C to +65°C Packaging contents:EX-6220, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The EX-6201 is an industrial 5-port Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block. 5-port 10/100Tx Fast Ethernet Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Terminal block for redundant DC input, 2x 12V to 48VDC Built-in relay output warning for power failure Robust metal housing, IP30 DIN-Rail Kit and metal plate for wall mounting Operating temperature range from -10°C to +65°C Packaging contents:EX-6201, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The EX-6200 is an ultra-compact industrial 5-port Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block. 5-port 10/100Tx Fast Ethernet Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Terminal block for redundant DC input, 2x 12V to 48VDC Robust, ultra-compact metal housing, IP30 DIN-Rail Kit and metal plate for wall mounting Operating temperature range from -10°C to +65°C Optionally available: EX-6200-T for operating temperature from -40°C to +75°C Packaging contents:EX-6200, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The EX-6203 is an industrial 6-port Ethernet unmanaged switch in a metal housing. It provides two fiber optic ports and four Fast Ethernet ports. Thanks to the redundant power supply of 2x 12 V - 48 VDC via a terminal block, it offers increased operational reliability. 4-Port 10/100Tx Fast Ethernet 2-Port 100Fx - SC/ST connector (Multi/Single Mode) Terminal block for redundant DC input, 2x 12V to 48VDC Built-in relay output warning for power failure Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Robust metal housing, IP30 Operating temperature range from -10°C to +65°C DIN-Rail Kit and metal plate for wall mounting Packaging contents:EX-6203, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The EX-6205 is a compact industrial 8-port Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12 V - 48 VDC via a terminal block. 8-port 10/100Tx Fast Ethernet Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Terminal block for redundant DC input, 2x 12V to 48VDC Built-in relay output warning for power failure Robust, compact metal housing, IP30 DIN-Rail Kit and metal plate for wall mounting Operating temperature range from -10°C to +65°C Optionally available: EX-6200-T for operating temperature from -40°C to +75°C Packaging contents: EX-6205, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The EX-6226PoE is a industrial 8-port Gigabit Ethernet unmanaged switch in a metal housing. Thanks to Power over Ethernet (PoE), it can be used to supply end devices such as IP telephones, IP cameras, WLAN access points, etc. with the necessary operating voltage via the data line. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 55VDC via a terminal block. 8-port 10/100/1000Tx Gigabit Ethernet Fully compliant to IEEE 802.3af/at PoE (PSE)  Built-in Power Booster Design for PoE/PoE+ Output Terminal block for redundant DC input, 2x 12V to 55VDC Built-in relay output warning for power failure and port link down Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Robust, compact metal housing, IP30 Operating temperature range from -10°C to +65°C DIN-Rail Kit and metal plate for wall mounting Packaging contents:EX-6226POE, RJ45 Protection caps, Wall mounting brackets, DIN-Rail kit, Manual

The EX-6225 is a compact industrial 8-port Gigabit Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block. 8-port 10/100/1000Tx Gigabit Ethernet Terminal block for redundant DC input, 2x 12V to 48VDC Built-in relay output warning for power failure Auto-MDI-MDIX, no "crossover cable" needed Plug and Play, no configuration and installation required Robust, compact metal housing, IP30 Operating temperature range from -10°C to +65°C DIN-Rail Kit and metal plate for wall mounting Packaging contents:EX-6225, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual

The extremely compact, industrial-grade 3-port Gigabit switch EX-62010POE-SFP is the perfect solution when space is at a premium. It can be used as a switch, media converter or PoE injector in the smallest of spaces. As it is operated with AC voltage (terminal block, 85-250VAC), no DC power supply unit is required, which also saves space. One of the two RJ45 ports provides up to 40W for connecting PoE powered devices (PD) such as IP cameras or IP telephones. Suitable SFP transceivers are available as accessories for the SFP slot. Thanks to the robust metal housing and the extended operating temperature range of -40°C to 75°C, the EX-62010POE-SFP is suitable for a wide range of applications, even in harsh environments. The scope of delivery includes a pre-assembled DIN rail kit and a wall mounting bracket. 2x 10/100/1000Tx RJ45 port, 1x 100/1000Fx SFP slot, auto detection Power supply for a PoE-capable remote network device, transmits data and power over the same cable Compliant with IEEE 802.3af/at Power over Ethernet (PoE), Mode/Alternative B Can be used as a switch, media converter or PoE injector Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports jumbo frames up to 9kByte Terminal block for AC power input, 85 to 250 VAC DC voltage converter for the PoE voltage range (42 - 57 VDC) Rugged, very compact metal housing, IP40 Includes DIN-Rail kit and wall mounting bracket Extended operating temperature range from -40°C to +75°C Packaging contents:EX-62010POE-SFP, DIN-Rail Kit (pre-assembled), Wallmount Kit, Manual

The tiny industrial-grade 5-port Gigabit switch EX-62021 offers full Gigabit performance on all ports despite its small size. The rugged metal housing and extended operating temperature range of -40°C to 80°C allow it to be used also in harsh environments. Unlike conventional Ethernet switches, power is supplied via a USB-C port, making it extremely versatile. 5-port 10/100/1000T Gigabit Ethernet USB-C port for power supply via almost any USB power source (e.g. USB-hub) Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports Jumbo Frames up to 9KBytes Plug and play, no configuration or installation required Rugged, very compact metal housing, IP40 DIN-Rail kit included Extended operating temperature range from -40°C to +80°C Packaging contents:EX-62021, DIN-Rail kit, USB-A to USB-C cable 90cm

The probably smallest industrial 10-port Gigabit PoE-Switch EX-62025PoE offers full Gigabit performance on all 10 ports despite its extremely small outer dimensions. Eight downlink ports provide up to 30W each for connecting PoE power devices (PD) such as IP cameras or IP phones. Thanks to the rugged metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a variety of applications even in harsh environments. Power is supplied from the terminal block (48-57VDC) and can be redundant to reduce operational downtime. The EX-62025PoE supports Auto-MDI/MDI-X and Auto-Negotiation. 10-Port 10/100/1000T Gigabit Ethernet Power up to 8 PoE-capable remote network devices, transfers data and power on one single cable Fully IEEE 802.3af compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W Maximum power delivered (PD): Type 1 = 12.95W / Type 2 = 25.50W Compliant with IEEE 802.3af/at Power Over Ethernet (PoE), Mode/Alternative B Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports jumbo frames up to 9KBytes Plug and play, no configuration and installation required Terminal block for redundant DC input, 2x 48 V to 57 VDC Rugged, very compact metal housing, IP40 Includes DIN-Rail Kit Extended operating temperature range from -40°C to +80°C Note:Refer to the STP cable grounding technical note. Packaging contents:EX-62025PoE, DIN-Rail Kit (pre-assembled), Manual

The probably smallest industrial 10-port Gigabit Switch EX-62025 offers full Gigabit performance on all 10 ports despite its extremely small outer dimensions. Thanks to the rugged metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a variety of applications even in harsh environments. Power is supplied from the terminal block (12-48VDC) and can be redundant to reduce operational downtime. The EX-62025 supports Auto-MDI/MDI-X and Auto-Negotiation. Included in delivery is a DIN rack kit (pre-assembled). 10-Port 10/100/1000T Gigabit Ethernet Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports jumbo frames up to 9KBytes Plug and play, no configuration and installation required Terminal block for redundant DC input, 2x 12 V to 48 VDC Rugged, very compact metal housing, IP40 Extended operating temperature range from -40°C to +80°C Includes DIN-Rail Kit Packaging contents:EX-62025, DIN-Rail Kit (pre-assembled), Manual Product Video EX-62025

The extremely compact, industrial-grade 5-port gigabit switch EX-62020POE-SFP offers full gigabit performance on all ports despite its small external dimensions. Up to 30W are available on each of the four RJ45 ports for connecting PoE Power Devices (PD) such as IP cameras or IP phones. The fifth Gigabit port is an SFP slot. Matching SFP transceivers are available as accessories. Thanks to the robust metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a variety of applications, even in harsh environments. Power is supplied via the terminal block (12~48VDC) and can also be redundant to reduce operational failures. A DIN-Rail Kit (pre-assembled) and a wall mounting bracket are included in the scope of delivery. 4x 10/100/1000Tx RJ45-Port, 1x 100/1000Fx SFP slot, auto detection Power up to 4 PoE-capable remote network devices, transfers data and power on one single cable Fully IEEE 802.3af compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W Maximum power delivered (PD): Type 1 = 12.95W / Type 2 = 25.50W Compliant with IEEE 802.3af/at Power Over Ethernet (PoE), Mode/Alternative B Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports jumbo frames up to 9kBytes Terminal block for redundant DC input, 2x 12 V to 48 VDC Scales the input voltage to the PoE voltage range (42 - 57VDC) Rugged, very compact metal housing, IP40 Includes DIN-Rail Kit and wall mounting bracket Extended operating temperature range from -40°C to +80°C Note:Refer to the STP cable grounding technical note. Packaging content:EX-62020PoE-SFP, DIN-Rail Kit (pre-assembled), Wallmount Kit, Manual

The extremely compact industrial 5-port Gigabit Switch EX-62020PoE offers full Gigabit performance on all ports despite its small external dimensions. The downlink ports provide up to 30W each for connecting PoE power devices (PD) such as IP cameras or IP phones. Thanks to the rugged metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a wide range of applications even in harsh environments. Power is supplied from the terminal block (12-48VDC) and can be redundant to reduce operational downtime. 5-Port 10/100/1000T Gigabit Ethernet Power up to 4 PoE-capable remote network devices, transfers data and power on one single cable Fully IEEE 802.3af compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W Maximum power delivered (PD): Type 1 = 12.95W / Type 2 = 25.50W Converts the input voltage to the PoE range of 42 to 57VDC Compliant with IEEE 802.3af/at Power Over Ethernet (PoE), Mode/Alternative B Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports jumbo frames up to 9KBytes Plug and play, no configuration and installation required Terminal block for redundant DC input, 2x 12V to 48VDC Scales the input voltage to the PoE voltage range (42 - 57VDC) Rugged, very compact metal housing, IP40 Extended operating temperature range from -40°C to +80°C Includes DIN-Rail Kit and wall mounting bracket Note:Refer to the STP cable earthing technical information. Packaging contents:EX-62020PoE, DIN-Rail Kit (pre-assembled), Wallmount Kit, Manual

The extremely compact industrial 5-port Gigabit Switch EX-62020 offers full Gigabit performance on all ports despite its small external dimensions. Thanks to the rugged metal housing and the extended operating temperature range from -40°C to 80°C, it is suitable for a variety of applications even in harsh environments. Power is supplied from the terminal block (12~48VDC) and can be redundant to reduce operational downtime. The EX-62020 supports Auto-MDI/MDI-X and Auto-Negotiation. Included in delivery is a DIN rack kit (pre-assembled) and a wall mounting bracket. 5-Port 10/100/1000T Gigabit Ethernet Auto-MDI/MDIX eliminates the need for crossover cables Supports auto-negotiation and 10/100Mbps half/full duplex and 1000Mbps full duplex Supports jumbo frames up to 9KBytes Plug and play, no configuration and installation required Terminal block for redundant DC input, 2x 12 V to 48 VDC Rugged, very compact metal housing, IP40 Extended operating temperature range from -40°C to +80°C Includes DIN-Rail Kit and wall mounting bracket Packaging contents:EX-62020, DIN-Rail Kit (pre-assembled), Wallmount Kit, Manual
