EX-6069-2
1 Gigabit Ethernet PCI Card (Realtek RTL8169SC)
The EX-6069-2 is a Gigabit Ethernet card designed for the PCI bus. The EX-6069-2 supports a data transfer rate of up to 1000Mbit per second. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-6069-2 supports Half and Full Duplex as well as NWay Auto-Negotation to automatically adapt to the speed in the network (10/100/1000 Mbit/s.). Furthermore, the card is equipped with Auto-MDI/MDI-X. In addition, it offers a very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Supports PCI Rev.2.3, 32-bit, 33MHz
Integrated Dual 10/100/1000 Transceiver
Supports Crossover Detection & Auto-Correction (for Crossover cable),
Support Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up Support
Supports Full Duplex Flow Control (IEEE 802.3x)
Supports IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), Supports PCI Message Signaled Interrupt (MSI)
Activity LED to check the data transfer
Chipset: Realtek RTL8169SC
Packaing Contents:EX-6069-2, Low Profile Bracket, Driver CD, Manual
EX-6071B
1 Gigabit Ethernet PCIe (x1) Card (Realtek RTL8111C)
The EX-6071B is a fast 1 Gigabit Ethernet card designed for the PCIe (x1) bus. The EX-6071B supports a data transfer rate of up to 1000Mbit per second. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-6071B supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000 Base-T Ethernet standards
Support Auto-MDI/MDI-X Auto (for Crossover cable)
Support Jumbo Frame up to 9Kbytes, Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up
Support Full Duplex Flow Control (IEEE 802.3x)
Support IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), support PCI Message Signaled Interrupt (MSI)
48KB Buffer Transmit/Receiver Chip
Activity LED to check the data transfer
Chipset: Realtek RTL8111C
Packaging Contents:EX-6071B, Low Profile Bracket, Manual
EX-6071C
1 Gigabit Ethernet PCIe (x1) Card (Realtek RTL8111G)
The EX-6071C is a fast 1 Gigabit Ethernet card designed for the PCIe (x1) bus. The EX-6071C supports a data transfer rate of up to 1000Mbit per second. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-6071C supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000 Base-T Ethernet standards
Support Auto-MDI/MDI-X Auto (for Crossover cable)
Support Jumbo Frame up to 9Kbytes, Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up
Support Full Duplex Flow Control (IEEE 802.3x)
Support IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), support PCI Message Signaled Interrupt (MSI)
48KB Buffer Transmit/Receiver Chip
Activity LED to check the data transfer
Chipset: Realtek RTL8111G
Packaging Contents:EX-6071C, Low Profile Bracket, Manual
Tip
New
EX-60120
10 Gigabit Ethernet PCIe (x2) Card (Realtek RTL8127AT)
The EX-60120 is a fast 10 Gigabit Ethernet card, designed for the PCIe (x2) bus. The EX-60120 supports a data transfer rate of up to 10000 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-60120 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000/2500/5000/10000Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Supports 10/100/1000/2500/5000/10000 Base-T Ethernet standards
Fully compatible with PCI Express 3.0 form factor x2
Supports Jumbo Frame up to 16KBytes, Pair Swap/Polarity/Skew correction
Auto-Negotiation with Extended Next Page capability (XNP)
Support Auto-MDI/MDI-X Auto (for Crossover cable)
Hardware ECC and CRC function
Support IEEE 802.3az-2010 Energy Efficient Ethernet (EEE)
Microsoft NDIS5, NDIS6 (IPv4, IPv6, TCP, UDP) Checksum and Segmentation Task-offload (Large send and Giant send) support
Supports IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.1Q VLAN tagging and IEEE 802.1ad Double VLAN
Supports IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Supports Virtual Machine Queue (VMQ) for Windows Server Hyper-V Installed Systems
Wake-on-LAN and ‘RealWoW!’ Technology (remote wake-up)
Activity LED data transfer mode
Supports Low Profile for small Computer cases with 8cm height
Chipset: Realtek RTL8127AT
Packaging Contents:EX-60120, Low Profile Bracket, Manual
EX-60121
10 Gigabit Power over Ethernet PCIe (x2) Card (Marvell AQC113CS)
The EX-60121 is a fast 10 Gigabit Power over Ethernet card designed for the PCIe (x2) bus. The EX-60121 supports a data transfer rate of up to 10000 Mbit per second. The PCI Express bus optimally supports the performance of the fast Marvell chipset, guaranteeing secure data transfer and excellent performance. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-60121 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000/2500/5000/10000 Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. Any end devices that support Power over Ethernet can be connected to the EX-60121 without additional PoE-Switches or PoE-Injectors. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Supports 10/100/1000/2500/5000/10000 Base-T Ethernet standard
Fully IEEE 802.3af compliant PoE (PSE) Type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W
Maximum power output (PD): Type 1 = 12.95 W / Type 2 = 25.50 W
Fully compliant with PCI Express 4.0
Support Jumbo Frame up to 16KBytes, Pair Swap/Polarity/Skew correction
MSI, MSI-X, LSO, RSS and IPv4/IPv6 checksum offloads for high performance and low CPU usage
Support IEEE 802.3az-2010 Energy Efficient Ethernet (EEE)
Wake On LAN and power management features
LED indicators for PoE, activity and data transfer mode
Chipset: Marvell AQC113CS
Packaging Contents:EX-60121, Low Profile Bracket
EX-6081
2.5 Gigabit Ethernet PCIe (x1) Card (Realtek RTL8125B)
The EX-6081 is a fast 2.5 Gigabit Ethernet card designed for the PCIe (x1) bus. The EX-6081 supports a data transfer rate of up to 2500 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-6081 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000/2500 Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000/2500 Base-T Ethernet Standard
Support Jumbo Frame up to 16KBytes, Pair Swap/Polarity/Skew Correction
Auto-Negotiation with Extended Next Page capability (XNP)
Support IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.1Q VLAN and IEEE 802.1ad Double VLAN
Support Auto-MDI/MDI-X Auto (for Crossover Cable)
Wake-on-LAN and `RealWoW!´ Technologie (Remote Wake-up)
Compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN
Microsoft NDIS5, NDIS6 (IPv4, IPv6, TCP, UDP), support for checksums and segmentation Task offload (Large Send and Giant Send)
Support IEEE 802.3az-2010 Energy Efficient Ethernet (EEE)
Hardware EXX and CRC function
Activity LED to check the data transfer
Chipset: Realtek RTL8125B
Packing Contents:EX-6081, Low Profile Bracket, Manual
EX-60111
2.5 Gigabit Ethernet PCIe (x1) Card (Realtek RTL8125B)
The EX-60111 is a fast 2.5 Gigabit Ethernet card designed for the PCIe (x1) bus. The EX-60111 supports a data transfer rate of up to 2500 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-60111 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000/2500 Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000/2500 Base-T Ethernet Standard
Support Jumbo Frame up to 16KBytes, Pair Swap/Polarity/Skew Correction
Auto-Negotiation with Extended Next Page capability (XNP)
Support IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.1Q VLAN and IEEE 802.1ad Double VLAN
Support Auto-MDI/MDI-X Auto (for Crossover Cable)
Wake-on-LAN and `RealWoW!´ Technologie (Remote Wake-up)
Compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN
Microsoft NDIS5, NDIS6 (IPv4, IPv6, TCP, UDP), support for checksums and segmentation Task offload (Large Send and Giant Send)
Support IEEE 802.3az-2010 Energy Efficient Ethernet (EEE)
Hardware EXX and CRC function
Activity LED to check the data transfer
Chipset: Realtek RTL8125B
Packing Contents:EX-60111, Low Profile Bracket, Manual
EX-6081POE
2.5 Gigabit Power over Ethernet PCIe (x1) Card (Realtek RTL8125B)
The EX-6081PoE is a fast 2.5 Gigabit Ethernet card designed for the PCIe (x1) bus. The EX-6081PoE supports a data transfer rate of up to 2500 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Larger amounts of data can thus be transferred faster and more efficiently in the network. The EX-6081PoE supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000/2500 Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. Any end devices that support Power over Ethernet can be connected to the EX-6081PoE without additional PoE-Switches or PoE-Injectors. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000/2500 Base-T Ethernet Standard
Fully IEEE 802.3af compliant PoE (PSE) Type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W
Maximum Power Delivered (PD): Type 1 = 15.4W / Type 2 = 30.0W
Support IEEE 802.1P Layer 2 Priority Encoding, IEEE 802.1Q VLAN and IEEE 802.1ad Double VLAN
Support Jumbo Frame up to 16KBytes, Pair Swap/Polarity/Skew Correction
Support IEEE 802.3az-2010 Energy Efficient Ethernet (EEE)
Compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN
Microsoft NDIS5, NDIS6 (IPv4, IPv6, TCP, UDP), support for checksums and segmentation Task offload (Large Send and Giant Send)
Support Auto-MDI/MDI-X Auto (for Crossover Cable)
Wake-on-LAN and `RealWoW!´ Technologie (Remote Wake-up)
Activity LED to check the data transfer
Chipset: Realtek RTL8125B
Packing Contents:EX-6081PoE, Low Profile Bracket, Manual
EX-6100POE
5 Port Gigabit Switch with 4 PoE Ports for Temperature from –40°C to +85°C
EX-6100PoE is a Gigabit Ethernet switch in metal housing with PoE function for up to 4 end devices such as IP phones, IP cameras, WLAN access points, etc. It supports 10/100/1000 Base-T Ethernet standard and is fully compliant with IEEE 802.3af/at POE standards. The EX-6100PoE operates as Power Source Equipment (PSE) = 34.20 W for the Powered Device (PD) = 25.50 W. The required power is supplied via the +48 - 57 V terminal block. The EX-6100PoE provides the user with greater installation flexibility by eliminating the need for the terminal device to be located in close proximity to a power outlet. It can also be used in the extended temperature range of -40C° to +85C°.
5x 10/100/1000Mbps Ethernet RJ45 ports
Power up to 4 PoE-capable remote network devices, transfers data and power on one single cable
Fully IEEE 802.3af/at compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W
Maximum Power Delivered (PD): Type 1: 12.95W / Type 2: 25.50W
Supports a extended temperature range from -40°C up to +85°C
Supports Jumbo Frames up to 9K Bytes
Auto-MDI/MDIX eliminates the need for crossover cables
Plug and play, no configuration and installation required
Terminal block for DC input 48V to 57VDC
ED status indicator of PoE power supply for each port
Small, rugged metal housing for critical applications
Wall or DIN-Rail mounting
Packaging contents:EX-6100PoE, DIN-Rail Kit, Manual
EX-6200-T
5-Port 10/100Tx industrial Ethernet switch, for Temperature from -40° to +75°C
The EX-6200-T is a compact industrial 5-port Ethernet unmanaged switch in a metal housing. It can be used in an extended temperature range from -40C° to +75C° and offers increased operational reliability thanks to the redundant power supply of 2x 12 V - 48 VDC via a terminal block.
5-Port 10/100Tx Fast Ethernet
Supports the extended temperature range from -40°C to +75°C
Auto-MDI-MDIX, does not require a “crossover cable”
Plug and play, no configuration and installation required
Terminal block for redundant DC input, 2x 12 V to 48 VDC
Robust Metal Case, IP30
Incl. DIN-Rail Kit and Metal Plate for wall mounting
Packaging contents:EX-6200-T, RJ45 Protection caps, Wall Mounting Brackets, DIN-Rail Kit, Manual
EX-6220
5-Port Industrial Ethernet Gigabit Unmanaged Switch (compact)
The EX-6220 is an ultra-compact industrial 5-port Gigabit Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block.
5-port 10/100/1000Tx Gigabit Ethernet
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Terminal block for redundant DC input, 2x 12V to 48VDC
Robust, ultra-compact metal housing, IP30
DIN-Rail Kit and metal plate for wall mounting
Operating temperature range from -10°C to +65°C
Packaging contents:EX-6220, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-6221
5-Port Industrial Gigabit Ethernet Unmanaged Switch
The EX-6221 is an industrial 5-port Gigabit Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block.
5-port 10/100/1000Tx Gigabit Ethernet
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Terminal block for redundant DC input, 2x 12V to 48VDC
Built-in relay output warning for power failure
Robust metal housing, IP30
DIN-Rail Kit and metal plate for wall mounting
Operating temperature range from -10°C to +65°C
Packaging contents:EX-6220, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-6201
5-Port Industrie Ethernet Switch
The EX-6201 is an industrial 5-port Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block.
5-port 10/100Tx Fast Ethernet
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Terminal block for redundant DC input, 2x 12V to 48VDC
Built-in relay output warning for power failure
Robust metal housing, IP30
DIN-Rail Kit and metal plate for wall mounting
Operating temperature range from -10°C to +65°C
Packaging contents:EX-6201, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-6200
5-Port Industrie Ethernet Switch, Kompakt
The EX-6200 is an ultra-compact industrial 5-port Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block.
5-port 10/100Tx Fast Ethernet
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Terminal block for redundant DC input, 2x 12V to 48VDC
Robust, ultra-compact metal housing, IP30
DIN-Rail Kit and metal plate for wall mounting
Operating temperature range from -10°C to +65°C
Optionally available: EX-6200-T for operating temperature from -40°C to +75°C
Packaging contents:EX-6200, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-6203
6-Port Industrial Ethernet Unmanaged Switch
The EX-6203 is an industrial 6-port Ethernet unmanaged switch in a metal housing. It provides two fiber optic ports and four Fast Ethernet ports. Thanks to the redundant power supply of 2x 12 V - 48 VDC via a terminal block, it offers increased operational reliability.
4-Port 10/100Tx Fast Ethernet
2-Port 100Fx - SC/ST connector (Multi/Single Mode)
Terminal block for redundant DC input, 2x 12V to 48VDC
Built-in relay output warning for power failure
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Robust metal housing, IP30
Operating temperature range from -10°C to +65°C
DIN-Rail Kit and metal plate for wall mounting
Packaging contents:EX-6203, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-6205
8-Port Industrial Ethernet Unmanaged Switch
The EX-6205 is a compact industrial 8-port Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12 V - 48 VDC via a terminal block.
8-port 10/100Tx Fast Ethernet
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Terminal block for redundant DC input, 2x 12V to 48VDC
Built-in relay output warning for power failure
Robust, compact metal housing, IP30
DIN-Rail Kit and metal plate for wall mounting
Operating temperature range from -10°C to +65°C
Optionally available: EX-6200-T for operating temperature from -40°C to +75°C
Packaging contents:
EX-6205, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-6226POE
8-Port Industrial Gigabit Ethernet Unmanaged PoE Switch
The EX-6226PoE is a industrial 8-port Gigabit Ethernet unmanaged switch in a metal housing. Thanks to Power over Ethernet (PoE), it can be used to supply end devices such as IP telephones, IP cameras, WLAN access points, etc. with the necessary operating voltage via the data line. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 55VDC via a terminal block.
8-port 10/100/1000Tx Gigabit Ethernet
Fully compliant to IEEE 802.3af/at PoE (PSE)
Built-in Power Booster Design for PoE/PoE+ Output
Terminal block for redundant DC input, 2x 12V to 55VDC
Built-in relay output warning for power failure and port link down
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Robust, compact metal housing, IP30
Operating temperature range from -10°C to +65°C
DIN-Rail Kit and metal plate for wall mounting
Packaging contents:EX-6226POE, RJ45 Protection caps, Wall mounting brackets, DIN-Rail kit, Manual
EX-6225
8-Port Industrial Gigabit Ethernet Unmanaged Switch
The EX-6225 is a compact industrial 8-port Gigabit Ethernet unmanaged switch in a metal housing. It offers increased operational reliability thanks to the redundant power supply of 2x 12V - 48VDC via a terminal block.
8-port 10/100/1000Tx Gigabit Ethernet
Terminal block for redundant DC input, 2x 12V to 48VDC
Built-in relay output warning for power failure
Auto-MDI-MDIX, no "crossover cable" needed
Plug and Play, no configuration and installation required
Robust, compact metal housing, IP30
Operating temperature range from -10°C to +65°C
DIN-Rail Kit and metal plate for wall mounting
Packaging contents:EX-6225, RJ45 Protection caps, Wall mounting brackets, DIN-Rail Kit, Manual
EX-60102
Dual 1 Gigabit Ethernet PCIe (x1) Card (Realtek RTL8111F)
The EX-60102 is a fast 1 Gigabit Ethernet card with two RJ45 ports, designed for the PCIe (x1) bus. The EX-60102 supports a data transfer rate of up to 1000 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Each port has its own Realtek chipset, allowing larger amounts of data to be transferred faster and more efficiently across the network. The EX-60102 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000 Base-T Ethernet standards
Support Auto-MDI/MDI-X Auto (for Crossover cable)
Support Jumbo Frame up to 9Kbytes, Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up
Support Full Duplex Flow Control (IEEE 802.3x)
Support IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), support PCI Message Signaled Interrupt (MSI)
48KB Buffer Transmit/Receiver Chip
Activity LED to check the data transfer
Chipset: 2x Realtek RTL8111F
Packaging Contents:EX-60102, Low Profile Bracket, Manual
EX-6072-3
Dual 1 Gigabit Ethernet PCIe (x1) Card (Realtek RTL8111H)
The EX-6072-3 is a fast 1 Gigabit Ethernet card with two RJ45 ports, designed for the PCIe (x1) bus. The EX-6072-3 supports a data transfer rate of up to 1000Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Each port has its own Realtek chipset, allowing larger amounts of data to be transferred faster and more efficiently across the network. The EX-6072-3 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000 Base-T Ethernet standards
Support Auto-MDI/MDI-X Auto (for Crossover cable)
Support Jumbo Frame up to 9Kbytes, Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up
Support Full Duplex Flow Control (IEEE 802.3x)
Support IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), support PCI Message Signaled Interrupt (MSI)
48KB Buffer Transmit/Receiver Chip
Activity LED to check the data transfer
Chipset: 2x Realtek RTL8111H
Packaging Contents:EX-6072-3, Low Profile Bracket, Manual
EX-6072-4K
Dual 1 Gigabit Ethernet PCIe (x1) Card with 4KV Isolation (Realtek RTL8111H)
The EX-6072-4K is a fast 1 Gigabit Ethernet card with two RJ45 ports, designed for the PCIe (x1) bus. it has galvanic isolation of up to 4KV for each RJ45 port. The EX-6072-4K supports a data transfer rate of up to 1000 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Each port has its own Realtek chipset, allowing larger amounts of data to be transferred faster and more efficiently across the network. The EX-6072-4K supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000 Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. A low profile bracket is supplied with the card for installation in a narrow PC housing.
Supports 10/100/1000 Base-T Ethernet standards
Supports 4KVrms galvanic isolation for each RJ45 connection
Supports Auto-MDI/MDI-X Auto (for Crossover cable)
Supports Jumbo Frame up to 9Kbytes, Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up
Supports Full Duplex Flow Control (IEEE 802.3x)
Supports IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), support PCI Message Signaled Interrupt (MSI)
48KB Buffer Transmit/Receiver Chip
Activity LED to check the data transfer
Chipset: 2x Realtek RTL8111H
Packaging Contents:EX-6072-4K, Low Profile Bracket, Manual
EX-60202
Dual 1 Gigabit Ethernet PCIe (x4) Card (Chipsatz Intel I350-AM2)
The EX-60202 is a fast 1 Gigabit Ethernet card with two RJ45 ports, designed for the PCIe (x4) bus. The EX-60202 supports a data transfer rate of up to 1000 Mbit per second. It supports half and full duplex as well as auto-negotiation for automatic adaptation to the network speed (10/100/1000 Mbps). The Intel chipset used guarantees the highest quality and reliability.
Supports 10/100/1000 Base-T Ethernet standard
Supports 4-lane 2.5 + 5GT/s PCI Express bus
Fully compliant with PCI Express 2.0
Supports Jumbo Frames up to 9KBytes
Automatic crossover detection (MDI/ MDI-X)
Supports Preboot eXecution Environment (PXE)
Supports Legacy and Message Signal Interrupt (MSI/MSI-X)
IEEE 802.3 auto-negotiator - automatic connection configuration for speed, duplex and flow control
Time stamping and IEEE 1588 Precision Time Protocol
IEEE 802.3az - Energy Efficient Ethernet (EEE)
Active State Power Management (ASPM)
Full wake-up support (APM/ACPI)
Latency Tolerance Reporting (LTR)
LED indicator for activity and data transfer mode
Original Intel chipset, new, not refurbished / B-goods
Chipset: Intel I350-AM2
Packaging Contents:EX-60202, Low Profile Bracket, Manual
EX-6072POE-2
Dual 1 Gigabit Power over Ethernet PCIe (x1) Card (Realtek RTL8111H)
The EX-6072PoE-2 is a fast 1 Gigabit Ethernet card with two RJ45 ports, designed for the PCIe (x1) bus. The EX-6072PoE-2 supports Power over Ethernet and a data transfer rate of up to 1000 Mbit per second. The PCI Express bus optimally supports the performance of the fast Realtek chipset, guaranteeing secure data transfer and excellent performance. Each port has its own Realtek chipset, allowing larger amounts of data to be transferred faster and more efficiently across the network. The EX-6072PoE-2 supports half and full duplex as well as NWay auto-negotation to automatically adapt to the network speed (10/100/1000 Mbps). Furthermore the card is equipped with Auto-MDI/MDI-X. It also offers very extensive support of various operating systems. Any end devices that support Power over Ethernet can be connected to the EX-6072PoE-2 without additional PoE-Switches or PoE-Injectors. A low-profile bracket is supplied with the card for installation in a narrow PC housing.
Support 10/100/1000 Base-T Ethernet standards
Fully IEEE 802.3af compliant PoE (PSE) type 1 = 15.40W and IEEE802.3at PoE+ (PSE) type 2 = 34.20W
Maximum Power Delivered (PD): Type 1 = 12.95W / Type 2 = 25.50W
Support Auto-MDI/MDI-X Auto (for Crossover cable)
Support Jumbo Frame up to 9Kbytes, Pair Swap/Polarity/Skew Correction
Wake-on-LAN and Remote Wake-up
Support Full Duplex Flow Control (IEEE 802.3x)
Support IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding
Microsoft NDIS 5 Checksum Offload (IP, TCP, UDP), supports PCI Message Signaled Interrupt (MSI)
48KB Buffer Transmit/Receiver Chip
Activity LED to check the data transfer
Chipset: 2x Realtek RTL8111H
Packaging Contents:EX-6072PoE-2, Low Profile Bracket, Manual
EX-60222
Dual 10 Gigabit Ethernet PCIe (x4) Card (Chipsatz Intel X550-AT2)
The EX-60222 is a fast 10 Gigabit Ethernet card with two RJ45 ports, designed for the PCIe (x4) bus. The EX-60222 supports a data transfer rate of up to 10000 Mbit per second. It supports half and full duplex as well as auto-negotiation for automatic adaptation to the network speed (10/100/1000/2500/5000/10000 Mbps). The Intel chipset used guarantees the highest quality and reliability.
Supports 10/100/1G/2.5G/5G/10G Base-T Ethernet standard
Supports 4-lane 2.5 + 5GT/s PCI Express bus
Fully compatible with PCI Express 3.0
Supports Jumbo Frames up to 9KBytes
Automatic cross-over detection (MDI/ MDI-X)
Supports Preboot eXecution Environment (PXE)
Supports Legacy and Message Signal Interrupt (MSI/MSI-X)
IEEE 802.3 auto-negotiator - Automatic link configuration for speed duplex and flow control
Time-stamping and synchronization of time sensitive applications
Scalable I/O for Linux environments (IPv4, IPv6,TCP/UDP)
IEEE 802.3az - Energy Efficient Ethernet (EEE)
Active State Power Management (ASPM)
MAC Power Management controls
Full wake up support (APM/ACPI)
Latency Tolerance Reporting (LTR)
LED indicators for activity and data transfer mode
Original Intel chipset, new, not refurbished / B-goods
Chipset: Intel X550-AT2
Packaging Contents:EX-60222, Low Profile Bracket, Manual
