Industrial PoE+ Gigabit Splitter 24VDC/30W
Product number:
EX-60321
GTIN/EAN:
4718359603211
Industrial PoE+ Gigabit Splitter 24VDC/30W
The Gigabit Ethernet PoE+ Splitter EX-60321 splits the signal of a PoE supplier (PSE) into data and power supply and outputs both signals separately. This allows non-PoE-capable Ethernet end devices (IP cameras, WLAN access points...) to be connected to a PoE switch or other PSE and use their power supply. It is compliant with the PoE+ standard IEEE 802.3at and provides a voltage of 24VDC with a power of max. 30W at the terminal block for feeding the end device. Thanks to the robust metal housing, it is suitable for a wide range of applications even in harsh environments. A DIN-Rail Kit (pre-assembled) is included in the delivery.
- Separates data and power supply of a PoE signal to power non-PoE capable Ethernet end devices
- Reduces system wiring, improves system stability/security, and reduces maintenance costs
- Voltage output at DC connector: 24VDC max. 30W (PD)
- Fully IEEE 802.3af/at/bt Power Over Ethernet (PoE) compliant
- 10/100/1000Base-TX Ethernet
- Plug and play, no configuration and installation required
- LED status indicators for power supply and PoE
- Rugged, compact metal housing, IP40
- Includes DIN-Rail Kit
Packaging contents:
EX-60321, Manual
| Connections: | RJ45 |
|---|---|
| Data transmission: | 1000Base-T |
| Interface: | Ethernet |
| Mounting Type: | DIN-Rail |
| Number of ports: | 2 |
| Power connection: | TB 24V/30W |
| Power over Ethernet: | Yes (PD) |
| Temperature range: | 0°C to +55°C |
